Product Type: Online UPS;

UPS Rating: 6,000 VA / 4,800 W;

Topology: Online / Double-conversion;

Configuration: Tower / Free-standing;

Input Connection: Hardwired / Terminal block;

Input Nominal Voltage: 230 V AC, adjustable to 220/230/240 V;

Input Voltage Range: 176–276 V without derating, 110–276 V with derating;

Input Frequency Range: 45–66 Hz;

Nominal Frequency: 50/60 Hz, automatic selection;

Input Phase: Single-phase;

Input Power Factor: >0.99;

Output Connection: Hardwired / Terminal block;

Output Nominal Voltage: 230 V AC, adjustable to 220/230/240 V;

Output Voltage Range: 220/230/240 V ±2%;

Output Frequency: 50/60 Hz;

Output Phase: Single-phase;

Output Waveform: Sine wave;

Output Power Factor: 0.8;

Output Voltage Distortion: <3% with linear load;

Automatic Voltage Regulation: Yes, through online double-conversion topology;

Efficiency at Maximum Load: 91%;

Efficiency in ECO Mode: 97%;

Internal Bypass: Yes;

Maintenance Bypass: Yes;

Overload Capacity: 105–110% for 5 min, 110–130% for 1 min, 130–150% for 10 s, >150% for 100 ms;

Short-Circuit Current: 82 A;

Battery Type: Sealed lead-acid;

Battery Quantity: 15;

Battery Rating: 12 V / 9 Ah;

Battery Management: Automatic battery test and deep-discharge protection;

Battery Replacement: Replaceable batteries;

Extended Battery Capability: Yes, via optional EBM;

Maximum Number of EBM: Up to 4;

Compatible EBM: Eaton 9EEBM180;

Communication: 1× USB HID-compliant port, 1× RS232 serial port, remote power-off terminal and communication slot;

Expansion Slot: 1× slot for optional Network-MS, ModBus-MS or Relay-MS card;

Ethernet Interface: No, optional network management card available;

Potential-Free Contact: Yes;

User Interface: LCD display;

Auto Shutdown: Yes;

Hot-Swap Power: No;

Software Compatibility: Eaton Intelligent Power Manager and Eaton Intelligent Power Protector;

Typical Runtime at 50% Load: Approximately 20 min;

Typical Runtime at 75% Load: Approximately 12 min;

Noise Level: <55 dB at 1 m;

Operating Temperature: 0°C to 40°C;

Relative Humidity: 0–95%, non-condensing;

Maximum Altitude: 3,000 m;

Protection Rating: IP20;

Color: Black;

Dimensions: 612.9 × 262.4 × 708.5 mm (D × W × H);

Weight: 68 kg;

Mounting: Free-standing; rack mounting kit not included;

Certifications: IEC/EN 62040-1, IEC/EN 62040-2, CE, EAC;

Compliance: CE Marked, TUV;

Package Contents: UPS, USB cable, serial cable, user manual;

Special Features: Online double-conversion topology, >0.99 input power factor, internal and maintenance bypass, LCD display, pure sine-wave output, automatic battery testing, deep-discharge protection, USB and RS232 communication, optional network/ModBus/relay communication cards and support for up to 4 extended battery modules;

Warranty: 1 year
