Product Type: Extended Battery Module (EBM);

Battery Module Voltage: 72 V DC;

Battery Type: Sealed lead-acid;

Battery Quantity: 12;

Battery Rating: 12 V / 9 Ah per battery;

Total Battery Capacity: 108 Ah at 12 V nominal battery rating;

Configuration: Rack / Tower;

Rack Format: 19-inch, 2U;

Compatible UPS Models: Eaton 5PX2200IRT2UG2 and 5PX3000IRT2UG2;

Maximum EBM Expansion: Up to 4 extended battery modules per compatible 5PX Gen2 UPS;

Rack Mounting Kit: Yes;

Color: Black/Silver;

Dimensions: 603 × 438 × 85.5 mm (D × W × H);

Weight: 40.4 kg;

Operating Temperature: Not specified by Eaton;

Relative Humidity: Not specified by Eaton;

Output Connections: None;

Output Voltage Distortion: 0% specified for linear load;

Package Contents: Extended battery module (EBM), EBM power cable, EBM detection cable, rack-mounting kit, mounting plate, quickstart guide and safety instructions;

Certifications: CE, cTUVus, EAC, Cm, UKCA, Ukr, RCM;

Compliance: IEC/EN 62040-1, IEC/EN 62040-2, IEC/EN 62040-3, RoHS, REACH, UL 1778, CSA 22.2;

Special Features: 72 V extended battery module for Eaton 5PX Gen2 UPS systems, 2U rack/tower design, front-accessible rack installation, integrated EBM power and detection connections, and support for up to 4 EBM modules to extend UPS runtime;

Warranty: 2 years
