Product Type: Online UPS;

UPS Rating: 3,000 VA / 2,700 W;

Topology: Online / Double-conversion with Power Factor Correction (PFC);

Configuration: Rack;

Rack Format: 19-inch, 2U;

Input Connection: IEC C20, 16 A;

Input Nominal Voltage: 230 V AC, adjustable to 200/208/220/230/240 V;

Input Voltage Range: 200–276 V without derating, 140–276 V with derating;

Input Frequency Range: 40–70 Hz;

Nominal Frequency: 50/60 Hz, autosensing or configurable as frequency converter;

Input Phase: Single-phase;

Input Power Factor: >0.99;

Output Voltage: 230 V AC, adjustable to 200/208/220/230/240 V;

Output Voltage Range: 200/208/220/230/240 V ±2%;

Output Frequency: 50/60 Hz;

Output Phase: Single-phase;

Output Waveform: Sine wave;

Number of Outputs: 6× IEC C13, 10 A + 1× IEC C19, 16 A;

Output Power Factor: 0.9;

Output Voltage Distortion: <3% with linear load, <5% with non-linear load;

Automatic Voltage Regulation: Yes, through online double-conversion topology;

Efficiency: >90% in normal mode, >94% in High Efficiency mode;

Internal Bypass: Yes, automatic;

Battery Type: Sealed, maintenance-free, valve-regulated lead-acid;

Battery Quantity: 6;

Battery Rating: 12 V / 9 Ah;

Battery Configuration: 72 V DC;

Battery Management: Temperature-compensated charging, automatic battery test and deep-discharge protection;

Battery Replacement: Replaceable batteries;

Extended Battery Capability: Yes, up to 4 external battery modules (EBM);

Compatible EBM: Eaton 9EEBM72R;

Runtime at Full Load: Approximately 7 min;

Runtime at Half Load: Approximately 20 min;

Communication: 1× USB port, 1× RS232 serial port and 1× mini-terminal block for Remote Power Off;

Expansion Slot: 1× slot for optional Network-M3, INDGW-M2 or Relay-MS communication card;

Ethernet Interface: No, optional network management card available;

Potential-Free Contact: Yes, via optional communication card;

User Interface: Multilingual LCD display;

Auto Shutdown: Yes;

Software Compatibility: Eaton power management software and virtual environments;

Noise Level: 45 dB at 1 m;

Operating Temperature: 0°C to 40°C;

Relative Humidity: 0–95%, non-condensing;

Maximum Altitude: 3,000 m;

Protection Rating: IP20;

Color: Black;

Dimensions: 608 × 438 × 86.5 mm (D × W × H);

Weight: 31.3 kg;

Mounting: 19-inch rack-mount, 2U; rack mounting kit included;

Certifications: EN IEC 62040-1:2019, IEC/EN 62040-2, IEC/EN 62040-3, CE, CB;

Compliance: CE Marked;

Package Contents: UPS, 2× IEC 10 A output cords (1.8 m), 1× 16 A European input power cord (1.8 m), rack-mounting kit, USB cable (1.8 m), quickstart guide and safety instructions;

Special Features: Online double-conversion topology with PFC, >0.99 input power factor, 0.9 output power factor, automatic bypass, multilingual LCD display, temperature-compensated battery charging, replaceable batteries, support for up to 4 external battery modules, USB and RS232 communication, Remote Power Off, optional Network-M3/INDGW-M2/Relay-MS communication card and 6× IEC C13 + 1× IEC C19 output configuration;

Warranty: 2 years
