Opis proizvoda
| Communication |
|
| Expansion slots |
One slot for optional communication card |
| Includes network card |
No |
| Potential free switch contact |
Yes |
| Software compatibility |
Eaton Intelligent Power Manager, Eaton Intelligent Power Protector |
| Type of interface |
Other |
| User interface |
Multilingual graphical LCD display |
Electrical input
| Input connection |
C20 |
| Input cord length |
1.8m |
| Input frequency range |
47-70 Hz (50 Hz system), 56.5-70 Hz (60 Hz system), 40 Hz in low sensitivity mode |
| Input nominal voltage |
230V default (200/208/220/230/240V) |
| Input voltage range |
160-294 V (adjustable to 150 V-294 V) |
| Nominal frequency |
50-60 Hz |
Electrical output
| Feed type |
1 |
| Output nominal voltage |
230V default (200/208/220/230/240V) |
| Output power factor |
1 |
| Output voltage range |
230 V (+6%/-10%) |
| Output waveform |
Sine wave |
| Receptacle |
(8) C13, (2) C19 |
| Topology |
Line-interactive |
| VA rating |
3000 VA |
| Voltage |
230V |
| Voltage distortion output (linear load) - max |
0 |
| Wattage |
3000 W |
Environmental
| Altitude |
3000 m |
| Noise level |
<40 dB at 1 meter |
| Relative humidity |
0-90% non-condensing |
| Temperature range |
0° to 40°C (32° to 104°F), batteries recommended max. 25°C (77°F) |
| Auto shutdown function |
Yes |
| Color |
Black/silver |
| Construction type |
482.6 mm (19 inch) device |
| Efficiency at max. load |
98 |
| Package contents |
|
| Phase (input) |
1 |
| Phase (output) |
1 |
| Rack mounting kit |
Yes |
Battery specifications
| Battery management |
ABM & Temperature compensated charging method (user selectable), Automatic battery test, deep discharge protection, automatic recognition of external battery units |
| Battery quantity |
6 |
| Battery rating |
12 V / 9 Ah |
| Battery replacement |
User replaceable |
| Battery type |
Lead-acid maintenance-free (replaceable) |
| Extended battery capability |
Yes |
Detalji proizvoda
- Kataloški broj
- 5PX3000IRT3UG2
- Barkod
- Jamstvo
- 36 months warranty
