Product Type: Line-Interactive UPS;

UPS Rating: 1,500 VA / 1,500 W;

Topology: Line-interactive;

Configuration: Rack / Tower;

Rack Format: 19-inch, 2U;

Input Connection: IEC C14;

Input Nominal Voltage: 230 V AC, adjustable to 200/208/220/230/240 V;

Input Voltage Range: 160–294 V, adjustable to 150–294 V;

Input Frequency Range: 47–70 Hz (50 Hz system), 56.5–70 Hz (60 Hz system), 40 Hz in low-sensitivity mode;

Nominal Frequency: 50/60 Hz;

Input Phase: Single-phase;

Output Voltage: 230 V AC, adjustable to 200/208/220/230/240 V;

Output Voltage Range: 230 V (+6% / -10%);

Output Frequency: 50/60 Hz;

Output Phase: Single-phase;

Output Waveform: Pure sine wave;

Number of Outputs: 8× IEC C13;

Output Power Factor: 1.0;

Automatic Voltage Regulation: Yes, AVR;

Efficiency at Maximum Load: 98%;

Surge Protection: Yes;

Battery Type: Lead-acid, maintenance-free, replaceable;

Battery Quantity: 4;

Battery Rating: 12 V / 9 Ah;

Battery Management: Eaton ABM technology, temperature-compensated charging, automatic battery test, deep-discharge protection and automatic recognition of external battery units;

Battery Replacement: User-replaceable;

Extended Battery Capability: Yes, up to 4 external battery modules (EBM);

Communication: 1× USB HID-compliant port, 1× RS232 serial port, Remote On/Off, Remote Power Off, output relay and dry contacts;

Expansion Slot: 1× slot for optional communication card;

Network Card Included: No;

Potential-Free Contacts: Yes;

User Interface: Multilingual graphical LCD display;

Auto Shutdown: Yes;

Software Compatibility: Eaton Intelligent Power Manager and Eaton Intelligent Power Protector;

Energy Metering: Yes, including managed outlet groups;

Noise Level: <40 dB at 1 m;

Operating Temperature: 0°C to 40°C;

Relative Humidity: 0–90%, non-condensing;

Maximum Altitude: 3,000 m;

Power Consumption: 31 W;

Color: Black/Silver;

Dimensions: 448 × 438 × 85.5 mm (D × W × H);

Weight: 22.4 kg;

Mounting: 19-inch rack-mount / tower installation, 2U; rack mounting kit included;

Certifications: CE, cTUVus, EAC, Cm, UKCA, Ukr, KCC, ENERGY STAR;

Compliance: IEC/EN 62040-1, IEC/EN 62040-2, IEC/EN 62040-3, RoHS, REACH, UL 1778, CSA 22.2;

Package Contents: Rack-mounting kit, 2× tower mounting supports, cable locking system, USB cable, serial cable, 2× IEC-IEC cables, quickstart guide and safety instructions;

Special Features: Unity power factor (VA=W), 98% efficiency, pure sine-wave output, AVR, multilingual graphical LCD display, Eaton ABM battery management, energy metering, user-replaceable batteries, support for up to 4 EBM units, USB and RS232 communication, dry contacts, Remote On/Off and Remote Power Off, optional communication card slot and versatile rack/tower installation;

Warranty: 3 years on electronics, 2 years on battery
