Product Type: Line-Interactive UPS;

UPS Rating: 3,000 VA / 2,700 W;

Topology: Line-interactive, high-frequency;

Configuration: Rack / Tower;

Rack Format: 19-inch, 2U;

Input Connection: IEC C20;

Input Nominal Voltage: 230 V AC;

Input Voltage Range: 184–276 V;

Input Frequency Range: 45–55 Hz at 50 Hz system, 55–65 Hz at 60 Hz system;

Input Phase: Single-phase;

Output Voltage: 230 V AC, adjustable to 220/230/240 V;

Output Voltage Range: 220/230/240 V (-10% / +6%);

Output Frequency: 50/60 Hz ±0.1 Hz;

Output Phase: Single-phase;

Output Waveform: Sine wave;

Number of Outputs: 8× IEC C13 + 1× IEC C19;

Output Power Factor: 0.9;

Automatic Voltage Regulation: Yes, AVR;

Efficiency at Maximum Load: 97%;

Surge Protection: Yes;

Battery Type: Lead-acid, maintenance-free, sealed;

Battery Quantity: 6;

Battery Rating: 12 V / 9 Ah;

Battery Management: Automatic battery test and deep-discharge protection;

Battery Replacement: User-replaceable;

Extended Battery Capability: No;

Communication: 1× USB HID-compliant port, 1× RS232 serial port;

Expansion Slot: 1× slot for optional communication card;

Ethernet Interface: No, optional network management card available;

Remote Control: Remote On/Off and Remote Power Off;

User Interface: LCD display;

Auto Shutdown: Yes;

Software Compatibility: Eaton Intelligent Power Manager and supported operating systems;

Noise Level: <45 dBA;

Operating Temperature: 0°C to 40°C;

Relative Humidity: 20–90%, non-condensing;

Maximum Altitude: 3,000 m;

Color: Black;

Dimensions: 647 × 441 × 86.2 mm (D × W × H);

Weight: 35.3 kg;

Mounting: 19-inch rack-mount, 2U, or tower installation; rack mounting kit included;

Certifications: IEC/EN 62040-1, UL 1778, IEC/EN 62040-2, CE, EAC, cTUVus;

Compliance: CE Marked, TUV;

Package Contents: Input cable, rack-mounting kit, cable locking system, USB cable, serial cable, 2× IEC-IEC cables, quickstart guide and safety instructions;

Special Features: 3,000 VA / 2,700 W capacity, 0.9 output power factor, AVR, 97% efficiency, sine-wave output, LCD display for real-time status and measurements, USB and RS232 communication, automatic shutdown, optional communication card slot and versatile rack/tower installation;

Warranty: 2 years
